Indoor Monitor
ASL7001 | Apartment Indoor Monitor 7″ Touch Screen
7 inch IPS Touch Indoor Monitor - Slim Black Design with Alarm Inputs
Model No.
TH3-880S7-V1
Key Features
- Flat-surface black housing with ultra-thin 13 mm depth
- 5 mechanical quick-access buttons plus capacitive GUI touch panel
- 1024 x 600 IPS display for clear viewing
- 8 wired alarm inputs for fire, burglar, gas and guard sensors
- Elevator call dry contact output
- SIP 2.0 with Android and iOS app support
- Optional 2-wire Ethernet retrofit mode for legacy cabling
- Controlled DC output port for xenon or strobe call notification
- Optional Wi-Fi networking support for flexible installation
Specifications
| Power Supply | DC 12V 1A / PoE 24V |
|---|---|
| Power Consumption | 300mA working / 100mA standby |
| Mounting | Surface mounted |
| Display | 7 inch IPS LCD, capacitive touch, 1024 x 600 px |
| Input | 5 mechanical buttons + GUI touch |
| Alarm Inputs | 8 x dry contact |
| Interface | RJ45 |
| Protocol | TCP/IP, SIP 2.0 |
| Wiring | Ethernet / optional 2-wire retrofit |
| Call Output | Controlled DC output for xenon/strobe lamp |
| Dimensions | 208 x 155 x 13 mm |
| Operating Temp. | 0 - 55 C |
